12.5 Random Effects

We have now discussed pooled OLS and fixed effects estimation (often called no-pooling). We will now shift to estimation strategies that involve partial-pooling.

Tradeoff between complete pooling and no-pooling (i.e., fixed effects).

  • Complete pooling ignores variation between groups BUT
  • No-pooling may overfit the data within group and prevents estimation of “level-2” effects.

To motivate partial-pooling, we can take a look at an example.

Example: What will Mookie Betts’s batting average be in 2018?

  • In March 2018, Mookie went 2 for 11. If we fit his average just based on his data \(n_{mookie}=11\), we get an average of .182.
  • Over the entire season, Mookie ended up with an average of .346. Is there any way we could have adjusted our initial estimate to end up with a more accurate estimate of what his average would be?
  • Possible solution: fit the average based on a combination of Mookie’s data (\(\bar y_{mookie}\)) and data from all players (\(\bar y_{all}\)). It will move Mookie’s estimate closer to the “grand” average across all players by partially pooling his data with the others.

12.5.1 Random effects models

In random effects estimation, for the \(ith\) observation, we allow the intercept \(\alpha\) to vary by some unit \(j\). Where \(j[i]\) refers to the group-level coding for the \(ith\) observation. Perhaps \(j=3\) for \(j[4]\), the 4th observation.

\[\begin{align*} Y_{ij} &= \alpha_{j[i]} + \beta x_{ij} + \epsilon_{ij} \end{align*}\]

The group index is a factor with \(J\) levels.

Approximation of multilevel estimates of the group average in case of no predictors:

\(\hat \alpha_j = \frac{\frac{n_j}{\sigma^2_y}\bar y_j + \frac{1}{\sigma^2_\alpha}\bar y_{all}}{\frac{n_j}{\sigma^2_y} + \frac{1}{\sigma^2_\alpha}}\)

  • Assume we have a random sample of \(n\) units within each \(j\), \(n_j\)
  • Then, our estimate for a given group \(j\) is a weighted average of observations within \(j\) (\(\bar y_j\)) and the mean overall \(j\)’s (\(\bar y_{all}\)).
  • These are weighted according to the variance in \(y\) within \(j\) (\(\sigma^2_y\)) and variance among the averages of \(y\) across \(j\) (\(\sigma^2_\alpha\))

This video by Ben Lambert shows how this idea of a “weighted average” extends to regression with covariates. Random effects provides a balance between fixed effects and OLS, no-pooling and pooling, which is why it is considered partial pooling.

  • When \(\sigma^2_\alpha\) is very small, random effects will be close to OLS.
  • If \(\sigma^2_\alpha\) is very big, then the weighted balance will be closer to fixed effects.

Differences with pooling and no pooling

  • Pooling- intercepts all fixed to \(\alpha\) (\(\sigma^2_{\alpha} = 0\))
  • No pooling- \(\alpha_j\)’s correspond to models fit within each \(j\). Do not come from a common distribution.
    • A downside: cannot include time-invariant group characteristics.
  • Partial pooling (shrinkage)- \(\alpha_j\)’s have a probabilitiy distribution \(\alpha_j \sim N(u_{\alpha}, \sigma^2_{\alpha})\). Has the effect of pulling estimates of \(\alpha_j\) toward the mean of all groups.
    • \(\alpha_j = u_{\alpha} + \eta_j\) where \(\eta_j\) is a group-level error term (model without group-level predictors)
    • Must assume \(\mathbf E(x_{ij}\alpha_{j[i]}) = 0\). Unmodeled, unmeasured characteristics about your group-level effects (e.g., countries) that affect the outcome are not correlated with the regressors in your model.
    • Good news: Can include group-level predictors: Now \(\alpha_j\) coeffcients have a distribution \(\alpha_j \sim N(U_j\gamma, \sigma^2_\alpha)\)

Scholars can have strong feelings about these choices, which often vary by subfield conventions along with the specifics of any research question. For example, the Green et al. piece advocating the use of fixed effects called pooling a ``Dirty Pool.” In response, Beck and Katz made the analogy that “Green, Kim, and Yoon’s fixed-effects”cure” for column 3 is akin to curing a cold with chemotherapy” (492).

12.5.2 Random Effects Implementation in R

If comparing with fixed effects, can useplm.

## Firm random effects
data("Grunfeld")
fit.re <- plm(inv~value+capital,
              data = Grunfeld,
              model = "random",
                index = c("firm"),
              effect = "individual")
coef(fit.re)["capital"]
 capital
0.308113

One approach to deciding whether to use fixed vs. random effects is the Hausman test, which assesses the correlation assumption.

## Compares beta hats for FE and RE and covariance
## Under null hypothesis of no correlation estimates should be similar
## Under null, RE preferred due to efficiency gains
fit.within <- plm(inv~capital+value,
                  data = Grunfeld,
                  model = "within",
                  index = c("firm", "year"))
phtest(fit.within, fit.re)

    Hausman Test

data:  inv ~ capital + value
chisq = 2.3304, df = 2, p-value = 0.3119
alternative hypothesis: one model is inconsistent

With a small p-value, we reject the null, suggesting fixed effects is preferred for this model. With a large p-value, we fail to reject the null, suggesting random effects is preferred. Note: while the test provides one way to adjudicate between fixed and random effects, it cannot tell you if the model you have specified is “correct.”

12.5.3 Using lme4 for random effects

More flexible package for random effects: lme4. Uses “REML” by default- a variation on MLE. Ben Bolker provides a great overview of the package here. Here is a video walking through the syntax and output.

library(lme4)
fit.re2 <- lmer(inv~ value + capital + (1 | firm), data = Grunfeld)

## extract model coefficients
fixef(fit.re2)["capital"]
  capital
0.3081881

WHERE ARE MY P VALUES?!?!?!?!

summary(fit.re2)$coefficients
               Estimate  Std. Error   t value
(Intercept) -57.8644245 29.37775852 -1.969668
value         0.1097897  0.01052676 10.429581
capital       0.3081881  0.01717127 17.947893

Not without controversy. Several ways to compute p-values in these models. This post describes three and provides the code.

For example, if you load the package lmerTest prior to running the model, it will include these results using the Satterthwaite method by default. Clicking on the pdf through this link will give you information on what this package does.

library(lme4)
library(lmerTest)
fit.re2 <- lmer(inv~ value + capital + (1 | firm), data = Grunfeld)

summary(fit.re2)
Linear mixed model fit by REML. t-tests use Satterthwaite's method [
lmerModLmerTest]
Formula: inv ~ value + capital + (1 | firm)
   Data: Grunfeld

REML criterion at convergence: 2195.9

Scaled residuals:
    Min      1Q  Median      3Q     Max
-3.4319 -0.3498  0.0210  0.3592  4.8145

Random effects:
 Groups   Name        Variance Std.Dev.
 firm     (Intercept) 7367     85.83
 Residual             2781     52.74
Number of obs: 200, groups:  firm, 10

Fixed effects:
             Estimate Std. Error        df t value Pr(>|t|)
(Intercept) -57.86442   29.37776  11.10912   -1.97   0.0743 .
value         0.10979    0.01053 120.76227   10.43   <2e-16 ***
capital       0.30819    0.01717 193.71234   17.95   <2e-16 ***
---
Signif. codes:  0 '***' 0.001 '**' 0.01 '*' 0.05 '.' 0.1 ' ' 1

Correlation of Fixed Effects:
        (Intr) value
value   -0.328
capital -0.019 -0.368
fit warnings:
Some predictor variables are on very different scales: consider rescaling

Can use output to interpret the nature of the variance. Note that the summary output includes a table for the Random Effects, the variance, and Std. Dev. of each. We can interpret the intercept row as the variability of the intercept across firms (firm-to-firm) variability. The residual is the left-over or within-firm variability. One use of this is to compute the intraclass correlation coefficient (ICC).

The ICC is the proportion of the variance explained by the grouping structure in the population. The Adjusted ICC indexes how strongly measurements in the same group resemble each other. This index goes from 0, if the grouping conveys no information, to 1, if all observations in a group are identical (Gelman & Hill, 2007, p. 258). If the value were really small, you might not need to include random effects for the grouping factor.

# install.packages("performance")
7367/(7367+2781)
[1] 0.7259559
performance::icc(fit.re2)
# Intraclass Correlation Coefficient

     Adjusted ICC: 0.726
  Conditional ICC: 0.140

12.5.4 Random Effects Extensions

Can have multiple levels. E.g., students (\(i\)) nested in classrooms (\(j\)) nested in schools (\(s\)). Each level may or may not have group-level predictors. Example:

  • \(Performance_{ijs} = \beta_{0js[i]} + \beta_1 Income_{ijs} + \beta_2 Gender_{ijs} + \epsilon_{ijs}\) where
  • \(\beta_{0js} = \gamma_{0s} + \gamma_{3}Teacher_{js} + r_{js}\) and
  • \(\gamma_{0s} = z + v_{s}\)
  • Combined: \(Performance_{ijs} = m + m_{1}Teacher_{js} + m_2 Income_{ijs} + m_3 Gender_{ijs} + v_{s} + r_{js} + \epsilon_{ijs}\)

Levels can be nested or non-nested. Students are nested in schools, but for a different example, survey questions may not be nested in a single poll. Perhaps some items are repeated across different polls.

Can allow slopes (regression coefficients to vary). Perhaps the effect of gender on student success varies by classroom. Then \(\beta_{2}\) becomes \(\beta_{j, 2} = \gamma_{1s} + r_{1js}\).

Let’s return to the Grunfeld data and fit the following model:

## firm and year random intercepts
fit.retwoways <- lmer(inv~ value + capital +
                        (1 | firm) +
                        (1 | year),
                      data = Grunfeld)
fixef(fit.retwoways)["capital"]
  capital
0.3106319

Sleep deprivation study: how is a subject’s reaction time associated with sleep deprivation?

data(sleepstudy)
## Random intercepts for subjects
fit.re3 <- lmer(Reaction ~ Days + (1 | Subject), data = sleepstudy)
fixef(fit.re3)["Days"]
    Days
10.46729
## Random intercepts for subject, varying slope for days
fit.re4 <- lmer(Reaction ~ Days + (Days | Subject), data = sleepstudy)
fixef(fit.re4)["Days"]
    Days
10.46729

Recall, the big assumption when adding random effects is that the unobserved group-level random disturbances caught through the intercept terms are not correlated with the regressors.

One suggestion is if concerned about correlation between predictors \(x_i\) and group effects \(\alpha_j\), add group means of regressors as predictors in the model.

  • See here and here.
  • Disentangles individual vs. contextual effect of regressors on outcome. First proposed by Mundlak (1978).

12.5.5 Extracting lmer output

Caution: coef(), ranef(), and fixef() all different.

  • coef() produces the set of regression coefficients associated with each group
## Example from random intercepts model
head(coef(fit.re3))
$Subject
    (Intercept)     Days
308    292.1888 10.46729
309    173.5556 10.46729
310    188.2965 10.46729
330    255.8115 10.46729
331    261.6213 10.46729
332    259.6263 10.46729
333    267.9056 10.46729
334    248.4081 10.46729
335    206.1230 10.46729
337    323.5878 10.46729
349    230.2089 10.46729
350    265.5165 10.46729
351    243.5429 10.46729
352    287.7835 10.46729
369    258.4415 10.46729
370    245.0424 10.46729
371    248.1108 10.46729
372    269.5209 10.46729
  • fixef() produces the set of fixed effects regression coefficients– similar to OLS– with global intercept.
## Example from random intercepts model
fixef(fit.re3)
(Intercept)        Days
  251.40510    10.46729
  • ranef() produces the set of random effects as deviations from the global estimates
## Example from random intercepts model
head(ranef(fit.re3)$Subject)
    (Intercept)
308   40.783710
309  -77.849554
310  -63.108567
330    4.406442
331   10.216189
332    8.221238
## Note the relationship between the three for the first [1] subject
fixef(fit.re3)[1] + ranef(fit.re3)$Subject[1,]
(Intercept)
   292.1888
coef(fit.re3)$Subject[1,1]
[1] 292.1888

12.5.6 Generating predicted values for each unit

## Manual
allsubjects <- unique(sleepstudy$Subject)
for(i in 1:nrow(sleepstudy)){
  n <- as.character(sleepstudy$Subject[i])
  sleepstudy$subjectRE[i] <- ranef(fit.re3)$Subject[n, 1]
}

## XB like usual, but need to add random effects
yhat <-  model.matrix(fit.re3)%*%fixef(fit.re3) + sleepstudy$subjectRE

## Compare to Automatic
cbind(yhat, fitted(fit.re3), predict(fit.re3, type = "response"))[1:5,]
      [,1]     [,2]     [,3]
1 292.1888 292.1888 292.1888
2 302.6561 302.6561 302.6561
3 313.1234 313.1234 313.1234
4 323.5907 323.5907 323.5907
5 334.0580 334.0580 334.0580

Predicting out of sample. Can “ignore” random effects if desired.

  • This is often how people make predictions for hypothetical values of the main covariates– without specifying specific groups.
predict(fit.re3, newdata= data.frame(Days = 4), type = "response", re.form = NA)
       1
293.2742
fixef(fit.re3)[1] + 4*fixef(fit.re3)[2]
(Intercept)
   293.2742

Compare predictions if we ignored the random effects:

cbind(yhat,
      predict(fit.re3, type = "response"),
      predict(fit.re3, type = "response", re.form=NA),
      model.matrix(fit.re3)%*%fixef(fit.re3))[1:5,]
      [,1]     [,2]     [,3]     [,4]
1 292.1888 292.1888 251.4051 251.4051
2 302.6561 302.6561 261.8724 261.8724
3 313.1234 313.1234 272.3397 272.3397
4 323.5907 323.5907 282.8070 282.8070
5 334.0580 334.0580 293.2742 293.2742

12.5.7 Week 11 Tutorial

In this section, we are going to again use data from the CDC on national and state-level COVID hospitalizations and positive case increases between July 2020- end September 2020 to give some examples of how to visualize random effects.

Let’s load the state data.

library(rio)
states <- import("https://github.com/ktmccabe/teachingdata/blob/main/states.RData?raw=true")
head(states)
           date hospitalizedCurrently positiveIncrease state
8849 2020-09-30                    53              104    AK
8850 2020-09-30                   776             1147    AL
8851 2020-09-30                   484              942    AR
8853 2020-09-30                   560              323    AZ
8854 2020-09-30                  3267             3200    CA
8855 2020-09-30                   264              511    CO

Let’s fit a random effects model with random intercepts for states.

## Random Effects
library(lme4)
library(lmerTest)
fit.re <- lmer(hospitalizedCurrently ~ positiveIncrease
               + (1 | state), data=states)
summary(fit.re)
Linear mixed model fit by REML. t-tests use Satterthwaite's method [
lmerModLmerTest]
Formula: hospitalizedCurrently ~ positiveIncrease + (1 | state)
   Data: states

REML criterion at convergence: 72042.8

Scaled residuals:
     Min       1Q   Median       3Q      Max
-21.4649  -0.1578   0.0012   0.1414  12.3407

Random effects:
 Groups   Name        Variance Std.Dev.
 state    (Intercept) 439843   663.2
 Residual             194044   440.5
Number of obs: 4780, groups:  state, 53

Fixed effects:
                  Estimate Std. Error        df t value Pr(>|t|)
(Intercept)      3.273e+02  9.160e+01 5.131e+01   3.573 0.000779 ***
positiveIncrease 5.317e-01  7.745e-03 4.774e+03  68.644  < 2e-16 ***
---
Signif. codes:  0 '***' 0.001 '**' 0.01 '*' 0.05 '.' 0.1 ' ' 1

Correlation of Fixed Effects:
            (Intr)
positvIncrs -0.078
fit warnings:
Some predictor variables are on very different scales: consider rescaling
performance::icc(fit.re)
# Intraclass Correlation Coefficient

     Adjusted ICC: 0.694
  Conditional ICC: 0.325

The function dotplot from the lattice package provides a fast way to visualize the random effects of the model.

library(lattice)
dotplot(ranef(fit.re), condVar=TRUE)
$state

The merTools package also has many useful functions. For example, the plotREsim function acts similar to the dotplot function and will plot the random effects for each group.

## install.packages("merTools")
library(merTools)
plotREsim(REsim(fit.re), labs=TRUE)+
  coord_flip()

The package also has a tool for plotting the coefficient results with confidence intervals constructed through simulation. If you had several variables, the plot would display all coefficients.

feEx <- FEsim(fit.re, 1000)
head(feEx)
              term        mean      median           sd
1      (Intercept) 331.0009191 330.4975284 93.053361870
2 positiveIncrease   0.5320422   0.5320992  0.007765486
plotFEsim(feEx) +
  theme_bw() +
  labs(title = "Coefficient Plot",
       x = "Median Effect Estimate",
       y = "Hospitalizations")

For more on this tool’s capabilities, particularly as it relates to generating predicted values, see here.

Finally, let’s try another model using the sleepstudy data to show how the plots can also incorporate varying slopes.

library(lme4)
data("sleepstudy")
## Random intercepts for subject, varying slope for days
fit.re4 <- lmer(Reaction ~ Days + (Days | Subject), data = sleepstudy)
library(merTools)
plotREsim(REsim(fit.re4), labs=TRUE)+
  coord_flip()

12.5.8 Generalized LMER

Generalized Linear Mixed Effects Regression: glmer() is to lmer() as glm() is to lm(). Example:

## What if reaction time was dichotomous?
sleepstudy$rdi <- ifelse(sleepstudy$Reaction >
                         mean(sleepstudy$Reaction), 1, 0)

## GLMER with logit
fit.glmer <- glmer(rdi ~ Days + (1 | Subject),
                   data = sleepstudy,
                   family = binomial(link = "logit"))

Generating predicted probabilities for each unit

## Manual
allsubjects <- unique(sleepstudy$Subject)
for(i in 1:nrow(sleepstudy)){
  n <- as.character(sleepstudy$Subject[i])
  sleepstudy$subjectRE[i] <- ranef(fit.glmer)$Subject[n, 1]
}

## XB like usual, but need to add random effects
py <-  plogis(model.matrix(fit.glmer)%*%fixef(fit.glmer) + sleepstudy$subjectRE)

## Compare to Automatic
cbind(py, fitted(fit.glmer), predict(fit.glmer, type = "response"))[1:5,]
       [,1]      [,2]      [,3]
1 0.1047843 0.1047843 0.1047843
2 0.1721090 0.1721090 0.1721090
3 0.2696603 0.2696603 0.2696603
4 0.3960526 0.3960526 0.3960526
5 0.5380430 0.5380430 0.5380430
